Specifications

Technical Data

• Visualization: Web Visu
• Baud rate: 10/100 Mbit/s
• Transmission medium: Twisted Pair S-UTP; 100 Ω; Cat. 5; 100 m maximum cable length
• Transmission performance: Class D per EN 50173
• Power supply: 230 VAC, 50 … 60 Hz
• Standards/Specifications: DIN EN 61439-1/2:2009

Connection Data

• Connection technology: communication/fieldbus: EtherNet/IPTM: 2 x RJ-45; Modbus TCP/UDP: 2 x RJ-45
• Connection technology: supply: 1 x 3-pole snap-in plugs (WAGO Item 770-713)

Physical Data

• Width: 350 mm
• Height from upper-edge of DIN-rail: 140 mm
• Depth: 250 mm

Mechanical Data

• Mounting type: Wall, screw mount
• Mounting (note): Interior area, e.g., intermediate floors, suspended ceiling

Material Data

• Housing material: Galvanized steel plate, material DC01 hot-dip galvanized, raw
• Fire load: 21.181 MJ
• Weight: 6396.004 g

Environmental Requirements

• Surrounding air temperature (operation): -5 … 45 °C
• Surrounding air temperature (storage): -20 … 70 °C
• Protection type: IP20
• Pollution degree (5): 2
• Mounting position: Any

Commercial Data

• Packaging type: Not packed
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821648147
• Customs tariff number Sales Organisation Germany: 85371091990
