Features

Approvals

• Underwriters Laboratories Inc., UL, E175199, UL 61010-2-201

Specifications

Technical Data

• Communication: Web browser || Web browser (HTML5)
• ETHERNET protocols: DHCP || DNS || FTP || FTPS || HTTP || HTTPS || SSH
• Visualization: Web Visu || Target Visu
• Operating system: Real-time Linux (with RT-Preempt patch)
• Processor: ARM® Cortex® A9 Quad Core 1.0 GHz
• Baud rate (communication/fieldbus 1): 10/100 Mbit/s
• Baud rate: ETHERNET: 10/100 Mbit/s
• Main memory (RAM): 2 GB, DDR3-SDRAM
• Internal memory (flash): 4 GB, eMMC
• Non-volatile hardware memory (2): 128 kByte
• Memory card type: MicroSD (max. 2 GB); microSDHC (max. 32 GB)
• Interfaces (USB): 2 x USB-2.0-Buchsen, Typ A; 1 x USB-OTG-Buchse, Typ C
• Onboard I/Os: 4 x DIO, configurable
• Indicators: 3-color LED – red, green, blue; 4 red/green LEDs
• Supply voltage: 24 VDC, SELV (18 … 31.2 V); LPS; mit Verpolungsschutz
• Max. input current (24 V): 120 mA
• Operating power: 2.9 W; without USB load; 9.4 W; with USB load

Connection Data

• Connection technology: communication/fieldbus: Ethernet: 2 x RJ-45; CANopen: 1 x D-sub 9 plug; RS-232/-485 serial interface: 1 x D-sub 9 socket

Physical Data

• Width: 65 mm / 2.559 inch
• Height: 123 mm / 4.843 inch
• Depth: 115 mm / 4.528 inch

Mechanical Data

• Weight: 600.000 g
• Housing material: Aluminum, powder-coated

Environmental Requirements

• Surrounding air temperature (operation): -20 … 60 °C
• Surrounding air temperature (storage): -20 … 80 °C
• Protection type: IP20
• Relative humidity (without condensation): 90 %
• Mounting type: DIN-35 rail
• Fire load: 0.000 MJ

Commercial Data

• Country of origin Sales Organisation Germany: DE
• GTIN: 4055144055474
• Customs tariff number Sales Organisation Germany: 84714100000
