Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Ratings Per Ul

• Approvals per: UL 1059

Ratings Per Csa

• Approvals per: C22.2 No 158

Connection 1

• Connection technology: Screw-type connection
• Actuation type: Slot screwdriver; (6.5 x 1.2) mm blade
• Connectable conductor materials: Copper
• Nominal cross-section: 35 mm²
• Solid conductor: 1.5 … 50 mm² / 16 … 1/0 AWG
• Stranded conductor: 1.5 … 50 mm² / 16 … 1/0 AWG
• Fine-stranded conductor: 1.5 … 50 mm² / 16 … 1/0 AWG
• Fine-stranded conductor; with insulated ferrule: 1.5 … 35 mm² / 16 … 2 AWG
• Note (conductor cross-section): Connecting 50 mm² is only possible on a copper DIN 35 x 15 rail (2.3 mm thick).
• Strip length: 18 mm / 0.71 inch
• Wiring direction: Side-entry wiring
• Screw thread: M6

Physical Data

• Width: 16.1 mm / 0.634 inch
• Height: 59 mm / 2.323 inch
• Depth from upper edge of DIN-rail: 65.5 mm / 2.579 inch

Mechanical Data

• Tightening torque: 3.2 … 3.7 Nm
• Design: Horizontal type
• Mounting type: DIN-rail 35 x 15
• Marking level: Side marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.000 MJ
• Weight: 85.080 g

Environmental Requirements

• Continuous operating temperature: -35 … +105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143940498
• Customs tariff number Sales Organisation Germany: 85369010000
