Features

• Fuse-protected voltage tap for measurement purposes
• Safe protection through integrated fuse with indicator (measurement line/device)
• WAGO push-in termination technology
• WAGO labeling options (WMB markers or marking strips)

Specifications

Notes

• Note: Spare fuse: WAGO 855-8020

Output – Voltage Tap

• Rated voltage: AC 400 V
• Fuse (voltage path): 2 A; 450 V; F; 70 kA; 5 x 25 mm (WAGO 855-8020)

Connection Data

• Connection technology: Push-in CAGE CLAMP®
• WAGO Connector: WAGO 2624 Series
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 10 … 12 mm / 0.39 … 0.47 inch

Physical Data

• Width: 61 mm / 2.402 inch
• Height: 14 mm / 0.551 inch
• Depth: 48 mm / 1.89 inch

Mechanical Data

• Mounting type: M8 mount || Installation on busbar

Material Data

• Fire load: 0.000 MJ
• Weight: 31.000 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 70 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Relative humidity: 5 … 85 % (without condensation)
• Operating altitude (max.): 2000 m
• Vibration resistance: 10g (industry; 5 … 2000 Hz; per IEC 60068-2-6); 4g (ship; 5 … 150 Hz; per IEC 60068-2-6)

Standards And Specifications

• Standards/Specifications: IEC 60947-7-3

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: NL
• GTIN: 4055143720052
• Customs tariff number Sales Organisation Germany: 85366990990
