Specifications

Electrical Data

• Nominal operating voltage: DC 24 V
• Power consumption at nominal supply voltage: ≤ 41 mA
• Voltage drop at input: 13 … 460 mV
• Measurement span (max.): 80 mA … 6 AAC (5 … 250 VAC)
• Response time: 40 ms
• Limiting continuous current: 0.05 A
• Switching power (resistive) (max.): DC 1.2 W
• Status indicator: Green LED; Output: 0 V (operation; current > 80 mA) || Red LED; Output: 24 VDC (current flow interruption; current < 80 mA)

Safety And Protection

• Rated voltage: 250 V
• Rated surge voltage: 4 kV
• Pollution degree: 2
• Dielectric strength, input/output (AC, 1 min): 2 kVrms

Physical Data

• Height from upper-edge of DIN-rail: 82.5 mm / 3.25 inch
• Depth: 52 mm / 2.047 inch

Mechanical Data

• Mounting type: Pluggable module for receptacle terminal blocks
• Housing design: Plug for carrier terminal blocks

Material Data

• Color: Light gray
• Fire load: 4.020 MJ
• Weight: 46.600 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 40 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4017332157476
• Customs tariff number Sales Organisation Germany: 85364900990
