Specifications

Electrical Data

• Nominal operating voltage: AC 230 V
• Nominal mains frequency range: 50 Hz
• Output voltage (DC) (max.): 27 V
• Output current (max.): 27 mA

Safety And Protection

• Dielectric strength, input/output (AC, 1 min): 2.5 kVrms

Physical Data

• Width: 25 mm / 0.984 inch
• Height from upper-edge of DIN-rail: 82.5 mm / 3.25 inch
• Depth: 52 mm / 2.047 inch

Mechanical Data

• Mounting type: Pluggable module for receptacle terminal blocks
• Housing design: Plug for carrier terminal blocks

Material Data

• Fire load: 0.494 MJ
• Weight: 57.000 g

Environmental Requirements

• Surrounding air temperature (operation): 0 … 70 °C
• Surrounding air temperature (storage): -40 … 80 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Standards And Specifications

• Standards/Specifications: EN 60664-1 || EN 60742

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4017332564403
• Customs tariff number Sales Organisation Germany: 85365005000
