Specifications

Electrical Data

• Nominal operating voltage: DC 24 V
• Operating voltage: DC 24 … 27.5 V
• Power consumption at nominal supply voltage: ≤ 34.6 mA
• Number of make/switch-on contacts: 1
• Limiting continuous current: 3 A
• Switching voltage (max.): AC 250 V; DC 120 V
• Switching power (resistive) (max.): AC 750 VA; DC 120 W

Safety And Protection

• Rated voltage: 250 V
• Rated surge voltage: 4 kV
• Pollution degree: 2
• Dielectric strength, input/output (AC, 1 min): 2.5 kVrms

Physical Data

• Width: 25 mm / 0.984 inch
• Height from upper-edge of DIN-rail: 82.5 mm / 3.25 inch
• Depth: 52 mm / 2.047 inch

Mechanical Data

• Mounting type: Pluggable module for receptacle terminal blocks
• Housing design: Plug for carrier terminal blocks

Material Data

• Color: Light gray
• Fire load: 0.445 MJ
• Weight: 34.000 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 40 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454344269
• Customs tariff number Sales Organisation Germany: 85369010000
