Specifications

Electrical Data

• Operating voltage: ≤ AC 35 V; ≤ DC 50 V
• Nominal current: 2.1 A
• Insulation resistance: ≥ 500 MΩ
• Specialty functions: With power jumper contacts || Crossover

Safety And Protection

• Dielectric strength, contact/contact (AC, 1 min): 1 kVrms

Connection Data

• Pole No.: 10
• Connection type (1): System
• Pluggable connectors: RJ-45 (shielded); with two additional power contacts
• Connection type 2: System
• Pole number 2: 10
• Connector 2: RJ-45 (shielded); with two additional power contacts
• Mating cycles: 1000
• Transmission length (max.): 100 m
• Connection cable: Cat. 5 (min.)

Physical Data

• Width: 30 mm / 1.181 inch
• Height: 85 mm / 3.346 inch
• Depth from upper edge of DIN-rail: 51 mm / 2.008 inch

Mechanical Data

• Mounting type: DIN-35 rail
• Housing design: Mounting carrier

Material Data

• Fire load: 0.492 MJ
• Weight: 34.300 g

Environmental Requirements

• Surrounding air temperature (operation): -40 … 85 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Relative humidity: ≤ 85% (non-condensing)

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454326135
• Customs tariff number Sales Organisation Germany: 85366990990
