Features

Approvals

• Underwriters Laboratories Inc., UL, E345416, UL 1977
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAA00000TU

Specifications

Electrical Data

• Specialty functions: With shield connection

Safety And Protection

• Protection type: IP20

Connection Data

• Pole No.: 8
• Connection type (1): System
• Pluggable connectors: RJ-45 (shielded)
• Connection type 2: System
• Pole number 2: 8
• Connection technology 2: IDC
• Solid conductor 2: 0.2 … 0.32 mm² / 24 … 22 AWG
• Stranded conductor 2: 0.2 … 0.32 mm² / 26/7 … 22/7 AWG
• Strip length 2: 0.8 … 1.6 mm / 0.03 … 0.06 inch
• Mating cycles: 750
• Connection cable: Cat. 6 (min.)

Physical Data

• Width: 26.8 mm / 1.056 inch
• Height: 81.4 mm / 3.205 inch
• Depth from upper edge of DIN-rail: 64.4 mm / 2.535 inch

Mechanical Data

• Mounting type: DIN-35 rail
• Housing design: Mounting carrier

Material Data

• Contact material (connector): Au over Ni
• Fire load: 0.000 MJ
• Weight: 51.000 g

Environmental Requirements

• Surrounding air temperature (operation): -10 … 60 °C
• Surrounding air temperature (storage): -40 … 70 °C
• Relative humidity: ≤ 95% (non-condensing)

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CH
• GTIN: 4055143292986
• Customs tariff number Sales Organisation Germany: 85366990990
