Specifications

Electrical Data

• Nominal operating voltage: DC 24 V
• Operating voltage: 20 … 26 VDC
• Power consumption at nominal supply voltage: ≤ 5.6 mA (per LED)

Connection Data

• Connection technology: CAGE CLAMP®
• WAGO Connector: WAGO 236 Series
• Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inch
• Note (conductor cross-section): 12 AWG: THHN, THWN

Physical Data

• Width: 47 mm / 1.85 inch
• Height from the surface: 31.5 mm / 1.24 inch
• Depth: 65.5 mm / 2.579 inch

Mechanical Data

• Mounting type: Mounting on DIN-rail via DIN-rail adapter
• Housing design: PCB

Material Data

• Fire load: 0.000 MJ
• Weight: 26.300 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 40 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454532109
• Customs tariff number Sales Organisation Germany: 85369010000
