Specifications

Notes

• Note: The communication cable is not electrically isolated.

Signaling And Communication

• Signaling: 1 x RS-232 cable
• Communication: RS-232 serial interface

Safety And Protection

• Protection type: IP20 (per EN 60529)

Connection Data

• Connection type (1): Module side (787-1675)
• Connection technology: 1 x 4-pole female connector (734-104) with strain relief
• Connection type 2: PC/controller side
• Connection technology 2: 1 x 9 pole D-sub socket
• Cable type: 3 x 0.34 mm²; shielded

Physical Data

• Cable length: 1.8 m

Material Data

• Fire load: 0.000 MJ
• Weight: 97.000 g

Environmental Requirements

• Surrounding air temperature (operation): -10 … 70 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821787402
• Customs tariff number Sales Organisation Germany: 85444290900
