Features

• Convenient wiring via extremely compact design
• Push-in termination of up to eight solid and stranded conductors
• Conductor range: 0.75 … 4 mm² “s” and 1.5 … 4 mm² “st”
• Any combination of conductor sizes is possible
• PUSH WIRE® connection terminates solid (“s+st”) copper conductors

Approvals

• DEKRA Certification B.V., KEMA/KEUR, 71-101844, EN 60669
• Underwriters Laboratories Inc., UL, 20180215-E201573, UL 467
• Underwriters Laboratories Inc., UL_Listed_667F, E69654, UL 486C
• DEKRA Certification B.V., CB, NL-49187, IEC 60998

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60998
• Nominal voltage (II/2): 450 V
• Rated surge voltage (II/2): 4 kV
• Rated current: 32 A
• Legend (ratings): (II / 2) ≙ Overvoltage category II / Pollution degree 2

Ratings Per Ul

• Approvals per: UL 486C
• Bemessungsspannung UL: 600 V
• Bemessungsstrom UL: 20 A

Connection 1

• Connection technology: PUSH WIRE®
• Actuation type: Push-in
• Connectable conductor materials: Copper
• Solid conductor: 0.75 … 4 mm² / 20 … 12 AWG
• Stranded conductor: 1.5 … 4 mm² / 18 … 12 AWG
• Conductor diameter: 1.6 … 2 mm / 20 … 12 AWG
• Strip length: 13 mm / 0.51 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 16.4 mm / 0.646 inch
• Height: 11.3 mm / 0.445 inch
• Depth: 18.6 mm / 0.732 inch

Material Data

• Color: Transparent
• Cover color: Gray
• Flammability class per UL94: V2
• Fire load: 0.000 MJ
• Weight: 2.620 g

Environmental Requirements

• Surrounding air temperature (operation): 85 °C
• Continuous operating temperature: -40 … +105 °C
• Temperature marking per EN 60998: T85

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143927666
• Customs tariff number Sales Organisation Germany: 85369010000
