Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 500 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 16 A

Connection 1

• Connection technology: CAGE CLAMP®
• Solid conductor: 0.5 … 2.5 mm² / 20 … 16 AWG
• Stranded conductor: 0.5 … 1.5 mm² / 20 … 16 AWG
• Fine-stranded conductor: 0.5 … 2.5 mm² / 20 … 16 AWG
• Strip length: 9 … 11 mm / 0.35 … 0.43 inch
• Wiring direction: Side-entry wiring

Material Data

• Color: Gray
• Insulation material: Polyamide (PA46)
• Flammability class per UL94: V0
• Fire load: 0.065 MJ
• Weight: 3.328 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821322115
• Customs tariff number Sales Organisation Germany: 85366990990
