Note (conductor cross-section): Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Strip length: 13 … 15 mm / 0.51 … 0.59 inch
Wiring direction: Front-entry wiring
Physical Data
Width: 15 mm / 0.591 inch
Height: 96.3 mm / 3.791 inch
Depth from upper edge of DIN-rail: 36.8 mm / 1.449 inch
Mechanical Data
Design: Horizontal type
Mounting type: DIN-35 rail
Marking level: Center/side marking
Material Data
Color: Gray
Insulation material: Polyamide (PA66)
Flammability class per UL94: V0
Fire load: 0.603 MJ
Weight: 42.410 g
Commercial Data
Packaging type: Box
Country of origin Sales Organisation Germany: DE
GTIN: 4045454789879
Customs tariff number Sales Organisation Germany: 85365080900
