Features

Approvals

• Physikalisch Technische Bundesanstalt (PTB), ATEx, PTB 00 ATEX 3113 UII 2 G Ex eb IIC Gb bzw. I M 2 Ex eb I Mb
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• DEKRA Certification B.V., KEMA/KEUR, 2160584.04, EN 60947
• CQST/CNEx, CCCEx, 2020312313000232, CNCA-C23-01
• Lloyds Register, LR, 91/20112 (E9), EN 60947
• DEKRA Certification B.V., CCA, NTR NL-7081, EN 60947

Specifications

Notes

• Safety information 1: Notice: This double potential terminal block cannot be commoned via adjacent jumpers.

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-1

Ex Information

• Rated voltage EN (Ex e II): 550 V
• Rated current (Ex e II): 15 A

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Strip length: 8 … 9 mm / 0.31 … 0.35 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 4 mm / 0.157 inch
• Height: 73 mm / 2.874 inch
• Depth from upper edge of DIN-rail: 27 mm / 1.063 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Center marking

Material Data

• Color: Light gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.114 MJ
• Weight: 5.946 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918506571
• Customs tariff number Sales Organisation Germany: 85369010000
