Features

• Protect your system against overvoltage
• Slim, space-saving design
• Control operational costs by preventing expensive, unplanned downtime
• High operational reliability and system uptime

Specifications

Electrical Data

• Nominal operating voltage: AC/DC 115 V
• Continuous operating voltage (max.): AC 180 V / DC 230 V
• Rated continuous current: 20 A
• Nominal discharge current (8/20 µs), line: 5 kA
• Protection level (8/20 μs): ≤ AC 650 V
• Capacitance: ≤ 2 pF

Connection Data

• Connection points (number): 2
• Connection technology: CAGE CLAMP®
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Strip length: 8 … 9 mm / 0.31 … 0.35 inch

Physical Data

• Width: 10 mm / 0.394 inch
• Height from upper-edge of DIN-rail: 39.5 mm / 1.555 inch
• Depth: 64 mm / 2.52 inch

Mechanical Data

• Design: With end plate; with direct connection to DIN-rail
• Mounting type: DIN-35 rail

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.265 MJ
• Weight: 12.316 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454194277
• Customs tariff number Sales Organisation Germany: 85369010000
