Features

Approvals

• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• American Bureau of Shipping, ABS, 20-HG1941090-PDA, EN 60947
• DEKRA Certification B.V., KEMA/KEUR, NTR NL-7135, EN 60947
• DEKRA Certification B.V., KEMA/KEUR, 2160584.31, EN 60947
• UL International Germany GmbH, UR, E45172, UL 1059

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 500 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 10 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 12 … 13 mm / 0.47 … 0.51 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 13 mm / 0.512 inch
• Height: 62 mm / 2.441 inch
• Depth from upper edge of DIN-rail: 54.5 mm / 2.146 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Side marking

Material Data

• Color: Gray
• Flammability class per UL94: V0
• Fire load: 0.429 MJ
• Weight: 26.448 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CN
• GTIN: 4044918558518
• Customs tariff number Sales Organisation Germany: 85369095000
