Features

Approvals

• DEKRA Certification B.V., CCA, 2195540.01, EN 60947
• UL International Germany GmbH, UR, E45172, UL 1059
• DEKRA Certification B.V., CCA, 2195540.01, IEC 60947
• DEKRA Certification B.V., CCA, NTR NL-7522, EN 60947

Specifications

Ratings Per Iec/En

• Operation status indicator: 120 V

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 12 … 13 mm / 0.47 … 0.51 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 16 mm / 0.63 inch
• Height: 85 mm / 3.346 inch
• Depth from upper edge of DIN-rail: 37 mm / 1.457 inch

Mechanical Data

• Design: Angled
• Mounting type: DIN-35 rail
• Marking level: Center marking

Material Data

• Color: Gray
• Flammability class per UL94: V0
• Fire load: 0.651 MJ
• Weight: 40.105 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454500870
• Customs tariff number Sales Organisation Germany: 85365080900
