Features

Approvals

• DEKRA Certification B.V., CCA, NTR NL-7522, EN 60947
• DEKRA Certification B.V., CCA, 2195540.01, IEC 60947
• DEKRA Certification B.V., CCA, 2195540.01, EN 60947
• Underwriters Laboratories Inc., cURus, E45172, UL 1059

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 12 … 13 mm / 0.47 … 0.51 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 8 mm / 0.315 inch
• Height: 122 mm / 4.803 inch
• Depth from upper edge of DIN-rail: 74 mm / 2.913 inch

Mechanical Data

• Design: Angled
• Mounting type: DIN-35 rail
• Marking level: Center marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.624 MJ
• Weight: 51.414 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CN
• GTIN: 4050821612773
• Customs tariff number Sales Organisation Germany: 85369010000
