Features

Approvals

• DEKRA Certification B.V., CSA, 1536072, C22.2 No. 158
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• DEKRA Certification B.V., CCA, NTR NL-7456/A1, EN 60947
• American Bureau of Shipping, ABS, 20-HG1941090-PDA
• DEKRA Certification B.V., KEMA/KEUR, 2187239.03, EN 60947
• Bureau Veritas S.A., BV, 07436/F0 BV, EN 60947
• UL International Germany GmbH, UL, E45172, UL 1059
• Lloyds Register, LR, 91/20112 (E9), EN 60947

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Fine-stranded conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Strip length: 16 … 17 mm / 0.63 … 0.67 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 12 mm / 0.472 inch
• Height: 94.5 mm / 3.72 inch
• Depth from upper edge of DIN-rail: 37.5 mm / 1.476 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Center marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.502 MJ
• Weight: 46.550 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454084561
• Customs tariff number Sales Organisation Germany: 85369010000
