Features

Approvals

• DEKRA Certification B.V., KEMA/KEUR, 71-101912, EN 60947
• DEKRA Certification B.V., CSA, 154112, C22.2
• DEKRA Certification B.V., CCA, NTR NL 7648, EN 60947
• Underwriters Laboratories Inc., UL, E45172, UL 1059

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-1
• Nominal voltage (III/3): 1000 V
• Rated surge voltage (III/3): 12 kV
• Rated voltage (III/3) 2: 1500 V
• Rated surge voltage (III/3) 2: 12 kV

Ratings Per Ul

• Approvals per: UL 1059
• Rated voltage UL (Use Group B): 600 V
• Rated current UL (Use Group B): 310 A
• Rated voltage UL (Use Group C): 600 V
• Rated current UL (Use Group C): 310 A

Ratings Per Csa

• Approvals per: C22.2 No 158
• Rated voltage CSA (Use Group B): 1000 V
• Rated current CSA (Use Group B): 310 A
• Rated voltage CSA (Use Group C): 1000 V
• Rated current CSA (Use Group D): 310 A

Connection 1

• Connection technology: POWER CAGE CLAMP
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Nominal cross-section: 185 mm²
• Solid conductor: 50 … 185 mm² / 1/0 AWG … 350 kcmil
• Stranded conductor: 50 … 185 mm² / 1/0 AWG … 350 kcmil
• Fine-stranded conductor: 50 … 185 mm² / 1/0 AWG … 350 kcmil
• Fine-stranded conductor; with insulated ferrule: 50 … 150 mm² / 1/0 AWG … 300 kcmil
• Fine-stranded conductor; with uninsulated ferrule: 50 … 185 mm² / 1/0 AWG … 350 kcmil
• Strip length: 45 … 47 mm / 1.77 … 1.85 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 128 mm / 5.039 inch
• Height from the surface: 123 mm / 4.843 inch
• Depth: 170 mm / 6.693 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: Mounting flange
• Marking level: Side marking

Material Data

• Color: Multicoloured
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 15.108 MJ
• Weight: 2257.900 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143657006
• Customs tariff number Sales Organisation Germany: 85369010000
