Features

Approvals

• DEKRA Certification B.V., CSA, 154112, C22.2 No. 158
• DEKRA Certification B.V., KEMA/KEUR, 71-101911, EN 60947
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• Lloyds Register, LR, 91/20112 (E9), EN 60947
• American Bureau of Shipping, ABS, 20-HG1941090-PDA, EN 60947
• Underwriters Laboratories Inc., AEx, E185892
• DEKRA Certification B.V., CCA, NTR NL-7707, EN 60947
• Bureau Veritas S.A., BV, 07436/F0 BV, EN 60947

Specifications

Notes

• Safety information 1: Only on DIN 35 x 15 rail; 2.3 mm thick, copper

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Connection 1

• Connection technology: POWER CAGE CLAMP
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 25 … 95 mm² / 4 … 4/0 AWG
• Stranded conductor: 25 … 95 mm² / 4 … 4/0 AWG
• Fine-stranded conductor: 25 … 95 mm² / 4 … 4/0 AWG
• Fine-stranded conductor; with insulated ferrule: 25 … 95 mm² / 4 … 4/0 AWG
• Fine-stranded conductor; with uninsulated ferrule: 25 … 95 mm² / 4 … 4/0 AWG
• Strip length: 35 mm / 1.38 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 25 mm / 0.984 inch
• Height: 107 mm / 4.213 inch
• Depth from upper edge of DIN-rail: 101 mm / 3.976 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Side marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 3.438 MJ
• Weight: 309.278 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: PL
• GTIN: 4045454204372
• Customs tariff number Sales Organisation Germany: 85369010000
