Features

Approvals

• Underwriters Laboratories Inc., AEx, E185892
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• Physikalisch Technische Bundesanstalt, ATEX, PTB 98 ATEX 3134 UII 2 G Ex eb IIC Gb or I M 2 Ex eb I Mb, EN 60079-0
• CQST/CNEx, CCCEx, 2020312313000177, CNCA-C23-01
• American Bureau of Shipping, ABS, 20-HG1941090-PDA, EN 60947
• Physikalisch Technische Bundesanstalt, IECEx, IECEx PTB 16.0001U Ex eb IIC Gb or Ex eb I Mb, IEC 60079-0
• DEKRA Certification B.V., CCA, NTR NL-7707, EN 60947
• DEKRA Certification B.V., CSA, 154112, C22.2 No. 158
• DEKRA Certification B.V., KEMA/KEUR, 71-101911, EN 60947

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-1
• Nominal voltage (III/3): 800 V
• Rated surge voltage (III/3): 8 kV
• Rated current: 32 A

Ratings Per Ul

• Approvals per: UL 1059
• Rated voltage UL (Use Group B): 600 V
• Rated current UL (Use Group B): 30 A
• Rated voltage UL (Use Group C): 600 V
• Rated current UL (Use Group C): 30 A

Ratings Per Csa

• Approvals per: C22.2 No 158
• Rated voltage CSA (Use Group B): 600 V
• Rated current CSA (Use Group B): 32 A
• Rated voltage CSA (Use Group C): 600 V
• Rated current CSA (Use Group D): 32 A

Connection 1

• Connection technology: CAGE CLAMP®
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 12 … 13 mm / 0.47 … 0.51 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 8 mm / 0.315 inch
• Module width: 8 mm / 0.315 inch

Mechanical Data

• Design: Angled
• Marking level: Center marking

Material Data

• Color: Gray
• Fire load: 0.132 MJ
• Weight: 9.283 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: PL
• GTIN: 4045454549626
• Customs tariff number Sales Organisation Germany: 85366990990
