Features

Approvals

• DEKRA Certification B.V., CCA, 2189801.01, EN 60947
• DEKRA Certification B.V., CCA, NTR NL 7468, EN 60947
• UL International Germany GmbH, cURus, E45172, UL 1059
• American Bureau of Shipping, ABS, 20-HG1941090-PDA

Specifications

Notes

• Safety information 1: 2-conductor female plugs cannot be used.

Ratings Per Iec/En

• Nominal voltage (III/3): 500 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 16 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Wiring direction: Front-entry wiring

Physical Data

• Width: 5 mm / 0.197 inch
• Height: 88.6 mm / 3.488 inch
• Depth from upper edge of DIN-rail: 37.1 mm / 1.461 inch

Mechanical Data

• Potentialkennzeichnung: L
• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Side marking

Material Data

• Color: Gray
• Flammability class per UL94: V0
• Fire load: 0.186 MJ
• Weight: 9.963 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454665722
• Customs tariff number Sales Organisation Germany: 85369010000
