Specifications

Electrical Data

• Nominal operating voltage: AC 24 V
• Continuous operating voltage (max.): AC 30 V
• Rated continuous current: 20 A
• Nominal discharge current (8/20 µs), line: 300 A
• Discharge current (max.): 1 kA
• Protection level (8/20 μs): ≤ AC 93 V
• Capacitance: ≤ 3.5 nF

Connection Data

• Connection points (number): 2
• Connection technology: CAGE CLAMP®
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
• Fine-stranded conductor; with insulated ferrule: 0.08 … 1.5 mm² / 28 … 14 AWG
• Strip length: 6 … 7 mm / 0.24 … 0.28 inch

Physical Data

• Width: 10 mm / 0.394 inch
• Height from upper-edge of DIN-rail: 40 mm / 1.575 inch
• Depth: 70 mm / 2.756 inch

Mechanical Data

• Mounting type: DIN-35 rail

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.257 MJ
• Weight: 12.100 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821868378
• Customs tariff number Sales Organisation Germany: 85369010000
