Features

• Two horizontal cable entries for both input and output.
• Fast and maintenance-free CAGE CLAMP® connection – a locking slide keeps the clampling unit in its open position
• Externally operable switch to activate or deactivate the network terminating resistor

Approvals

• UL International Netherlands B.V., UL, E175199 Sec.1, UL 508

Specifications

Technical Data

• Connection type: D-sub 9 plug
• Pole No.: 9
• Communication/fieldbus: CC-Link

Connection Data

• Connection type (1): CAGE CLAMP® terminal strip with locking slide (218 Series)
• Solid conductor: 0.08 … 0.5 mm² / 28 … 20 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inch

Physical Data

• Width: 45 mm / 1.772 inch
• Height: 16 mm / 0.63 inch
• Depth: 54 mm / 2.126 inch

Mechanical Data

• Connectable sheathed cable diameter: 4.5 … 9.5 mm
• Cable glands (number): 2
• Housing material: PA66-105-V2
• Weight: 34.100 g
• Color: Light gray

Environmental Requirements

• Surrounding air temperature (operation): 0 … 60 °C
• Surrounding air temperature (storage): -25 … 85 °C
• Protection type: IP20
• Relative humidity (without condensation): 95 %
• Fire load: 0.290 MJ

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821096030
• Customs tariff number Sales Organisation Germany: 85366990990
