Features

• Storage capacity: 1 GB
• Compatible to the CompactFlash® Specification, Version 3.0
• In line with the PC Card standard
• Supports TRUE IDE Mode, ATA Standard
• Three access modes:
• PC Card memory mode
• PC Card I/O mode
• TRUE IDE mode
• Error correction function: 4 bits / 512 bytes
• Supports auto-standby and idle status
• Supports multiword and ultra-direct memory access, multisector transfer and logical block addressing

Specifications

Technical Data

• Internal memory (flash): 1000 MB
• Write/read cycles (max.): Single: 20 Mbytes/s (max.) / 10 Mbytes/s (max.) Dual: 40 Mbytes/s (max.) / 20 Mbytes/s (max.)
• MTBF: 300,000 h
• Service life: 2,000,000 program/operating cycles

Physical Data

• Width: 42.8 mm
• Height from upper-edge of DIN-rail: 36.4 mm
• Depth: 3.3 mm

Material Data

• Fire load: 0.000 MJ
• Weight: 11.000 g

Environmental Requirements

• Surrounding air temperature (operation): -40 … 85 °C
• Surrounding air temperature (storage): -55 … 95 °C
• Relative humidity (without condensation): 95 %
• Vibration resistance: Per IEC 60068-2-6
• Shock resistance: Per IEC 60068-2-27

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: TW
• GTIN: 4050821045052
• Customs tariff number Sales Organisation Germany: 85235200009
