Features

Approvals

• Underwriters Laboratories Inc., UL, E198726, UL 121201
• Underwriters Laboratories Inc., UL, E175199, UL 61010-2-201

Specifications

Notes

• Note: The maximum range in the field decreases within buildings and varies depending on building materials and spatial geometry. Therefore, range specifications within buildings can only represent a typical value that can normally be achieved. More detailed information is available in the manual.

Technical Data

• Security encryption: Bluetooth® 2.1: NIST-Compliant; FIPS-Approved (Authentifizierung und Autorisierung, Verschlüsselung und Datensicherheit, Datenschutz und Diskretion); Bluetooth® 4.0 (Low Energy): AES-CCM Verschlüsselung
• Radio technology: Bluetooth® 2.1 || Bluetooth® 4.0 (Low Energy) || WLAN: IEEE 802.11 a, b, g, n, d, r
• Frequency band: ISM band, 2.4 GHz (Bluetooth®, WLAN); ISM band, 5 GHz (WLAN)
• Security authentication: WLAN: WEP 64/128; WPA; WPA-PSK und WPA2; TKIP und AES/CCMP; LEAP; PEAP inklusive MS-CHAP
• Transmission range: Up to 200 m
• Antenna: Internal broadband antenna for 2.4 GHz and 5 GHz
• Configuration options: Web-Based Management
• Supply voltage: 19 … 36 VDC

Connection Data

• Connection technology: communication/fieldbus: 1 x RJ-45
• Connection technology: supply: 1 x Female connector; 3-pole

Physical Data

• Height: 75 mm

Mechanical Data

• Mounting type: M50 through-panel installation (cut-out = 50.5 mm)

Material Data

• Fire load: 0.000 MJ
• Weight: 84.000 g
• Conformity marking: CE

Environmental Requirements

• Surrounding air temperature (operation): -40 … 65 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Protection type: IP67
• Note on protection type: Top (outside of unit): IP66/IP67/UL NEMA 4X ; Base (inside of unit): IP21

Commercial Data

• Country of origin Sales Organisation Germany: SE
• GTIN: 4055144057171
• Customs tariff number Sales Organisation Germany: 85176200000
