Features

Approvals

• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• Lloyds Register, LR, 91/20242 (E7), IEC 60998
• DEKRA Certification B.V., CSA, 70010891, C22.2
• DEKRA Certification B.V., CCA, 2110272.01, EN 60998
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• DEKRA Certification B.V., CCA, NTR-NL 6508, EN 60998
• American Bureau of Shipping, ABS, 19-HG1869868-PDA
• VDE Prüf- und Zertifizierungsinstitut, VDE, 40033303, EN 60998

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 400 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 18 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 16 AWG
• Strip length: 8 … 9 mm / 0.31 … 0.35 inch
• Pole No.: 12
• Wiring direction: Side-entry wiring

Physical Data

• Width: 109.7 mm / 4.319 inch
• Height from the surface: 17.1 mm / 0.673 inch
• Depth: 25 mm / 0.984 inch
• Module width: 8 mm / 0.315 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: Mounting flange
• Marking level: Side marking

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.531 MJ
• Weight: 31.480 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918594257
• Customs tariff number Sales Organisation Germany: 85369010000
