Features

Approvals

• DEKRA Certification B.V., CCA, NTR-NL 6509, EN 60998
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• Lloyds Register, LR, 91/20242 (E7), IEC 60998
• DEKRA Certification B.V., CCA, 2110272.02, EN 60998
• American Bureau of Shipping, ABS, 19-HG1869868-PDA

Specifications

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool || Push-button, one side
• Connectable conductor materials: Copper
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Strip length: 8 … 9 mm / 0.31 … 0.35 inch
• Pole No.: 1
• Wiring direction: Side-entry wiring

Physical Data

• Width: 10 mm / 0.394 inch
• Height from the surface: 23.3 mm / 0.917 inch
• Depth: 28.1 mm / 1.106 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: Snap-in foot
• Marking level: Side marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.060 MJ
• Weight: 3.890 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918614665
• Customs tariff number Sales Organisation Germany: 85369010000
