Features

Approvals

• UL International Germany GmbH, UL, E45171, UL 1977
• DEKRA Certification B.V., CCA, NL-47713, IEC 61984
• VDE Prüf- und Zertifizierungsinstitut, VDE, 40032309, EN 61984
• DEKRA Certification B.V., CCA, 2156138.01, EN 61984

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 61984
• Rated voltage (III/2): 500 V
• Rated surge voltage (III/2): 4 kV
• Rated current: 16 A
• Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2

Connection 1

• Connection technology: PUSH WIRE®
• Strip length: 11 … 12 mm / 0.43 … 0.47 inch
• Pole No.: 7

Physical Data

• Width: 35 mm / 1.378 inch
• Height from the surface: 18 mm / 0.709 inch
• Depth: 39 mm / 1.535 inch

Material Data

• Color: White
• Material group: I
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Clamping spring material: Chrome nickel spring steel (CrNi)
• Contact material: Electrolytic copper (ECu)
• Contact plating: Tin-plated
• Fire load: 0.273 MJ
• Weight: 19.365 g

Environmental Requirements

• Temperature stability: 105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: PL
• GTIN: 4044918546706
• Customs tariff number Sales Organisation Germany: 85366990990
