Features

• Flexible connection system with PUSH WIRE® connection
• Phase selection

Approvals

• DEKRA Certification B.V., CSA, 70048855, C22.2
• UL International Germany GmbH, UL, E45171, UL 1977
• Underwriters Laboratories Inc., UR, E45172, UL 1059
• VDE Prüf- und Zertifizierungsinstitut, VDE, 40029569, EN 61984

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60664-1
• Rated voltage (III/2): 400 V
• Rated surge voltage (III/2): 4 kV
• Rated current: 16 A
• Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2

Connection 1

• Connection technology: PUSH WIRE®
• Strip length: 11 … 12 mm / 0.43 … 0.47 inch
• Pole No.: 5

Physical Data

• Width: 30 mm / 1.181 inch
• Height: 31.4 mm / 1.236 inch
• Depth: 40 mm / 1.575 inch

Material Data

• Color: White
• Material group: I
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Clamping spring material: Chrome nickel spring steel (CrNi)
• Contact material: Electrolytic copper (ECu)
• Contact plating: Tin-plated
• Fire load: 0.444 MJ
• Weight: 23.622 g

Environmental Requirements

• Temperature stability: 105 °C

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918472050
• Customs tariff number Sales Organisation Germany: 85366990990
