Specifications

Electrical Data

• Inputs/outputs: 16-channel digital output
• Nominal operating voltage: DC 24 V
• Limiting continuous current: 1 A

Safety And Protection

• Rated voltage: 50 V
• Rated surge voltage: 0.8 kV
• Pollution degree: 2

Connection Data

• Connection type (1): System
• Pole number 1: 20
• Pluggable connectors: DIN 41651 male connector
• Pole number 2: 20
• Pole number 3: 20

Physical Data

• Width: 70 mm / 2.755 inch
• Height: 85 mm / 3.345 inch
• Depth from upper edge of DIN-rail: 45 mm / 1.771 inch

Mechanical Data

• Mounting type: DIN-35 rail

Material Data

• Fire load: 0.927 MJ
• Weight: 69.878 g

Environmental Requirements

• Surrounding air temperature (operation): -20 … 50 °C
• Surrounding air temperature (storage): -40 … 70 °C
• Relative humidity: ≤ 85% (non-condensing)

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143982719
• Customs tariff number Sales Organisation Germany: 85369010000
