Specifications

Notes

• Note: When using more than 10 wires, the maximum current per wire must be reduced to 0.7 A.

Electrical Data

• Inputs/outputs: 16 digital inputs or outputs
• Operating voltage: ≤ AC/DC 35 V
• Current per wire (max.): 1 A

Connection Data

• Compatible PLC Modules: Schneider TSX
• Compatible PLC I/O Card Types: TSX DEY 16FK || TSX DEY 32D2K || TSX DEY 64D2K || TSX DEZ 12D2K || TSX DMY 28FK || TSX DMY 28RFK || TSX DMZ 28DTK || TSX DMZ 64DTK || TSX DSY 32T2K || TSX DSY 64T2K
• Pole No.: 20
• Connection type (1): System
• Pole number 1: 20
• Pluggable connectors: Pluggable connector per DIN 41651; Female connector
• Connection type 2: System
• Pole number 2: 20
• Connector 2: Pluggable connector per DIN 41651; Female connector
• Cable type: LiYY
• Wire cross-section: 0.14 mm²
• Color code: Per DIN VDE 47100

Physical Data

• Cable length: 2 m

Material Data

• Fire load: 0.000 MJ
• Weight: 161.000 g

Environmental Requirements

• Surrounding air temperature (operation): -20 … 50 °C

Commercial Data

• Country of origin Sales Organisation Germany: FR
• GTIN: 4045454873776
• Customs tariff number Sales Organisation Germany: 85444290900
