Features

Approvals

• Underwriters Laboratories Inc., UL, E482462, UL 60950-1
• CQC, CCC, 2020010904320138

Specifications

System Requirements

• Memory: 4 GB
• Supported operating systems: Windows 7 || Windows 8 || Windows 10

Technical Data

• Marking method: Thermal transfer
• Print head: Glass layer, spring-mounted
• Print resolution: 300 dpi || 300 dpi (12 pixels/mm)
• Print speed (max.): Max. 127 mm/s (WAGO recommends 50.8 mm/s)
• Print width: 47 mm
• Print length (max.): 762 mm
• See-through/reflective sensor: Yes, centrally fixed
• Memory: 8 MB
• Beschriftungssoftware: Smart Script
• Interfaces: USB, RS-232, ETHERNET 10/100 Mbps
• Operating voltage: 100 … 240 VAC, 50 … 60 Hz (automatic adjustment)
• Safety approvals: CE (EMC)
• Operating display: Color TFT LCD with navigation button
• Ink ribbon: Reel outside diameter: 40 mm; core inside diameter 12.7 mm (0.5 inch); max. length 110 m; max. width 58 mm
• Ink ribbon (width): 50 mm / 1.969 inch
• Ink ribbon (length): 74 m / 360.9
• Ink ribbon roll outside diameter: 33 mm / 1.299 inch
• Ink ribbon core inside diameter: 12.5 mm / 0.492 inch
• Scope of delivery: Power supply + cable, 2 x roller (258‑5006 + 258‑5007), 1 x reel holder, 1 x ink ribbon (258-5005), Smart Script marking software and driver, USB cable, external unwinder, 2 empty cardboard roller cores, 1 x roll of marking strips (2009-110) and WMB Inline markers (2009-115)

Physical Data

• Height: 175 mm / 6.89 inch
• Width: 135 mm / 5.315 inch
• Depth: 245 mm / 9.646 inch

Material Data

• Weight: 3840.000 g
• Fire load: 0.000 MJ

Environmental Requirements

• Surrounding air temperature (storage): -20 … 50 °C
• Surrounding air temperature (operation): 5 … 40 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: TW
• GTIN: 4050821520993
• Customs tariff number Sales Organisation Germany: 84433210000
