Features

• simple circuits
• rapid, structured electrical installation

Approvals

• DEKRA Certification B.V., CCA, 2173495.02, EN 61535
• American Bureau of Shipping, ABS, 19-HG1868589-PDA
• Lloyds Register, LR, 02/20050 (E6), IEC 61984
• DEKRA Certification B.V., CCA, NL-32105, IEC 61535
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001Z6

Specifications

Connection 1

• Pole No.: 2

Physical Data

• Width: 25.8 mm / 1.016 inch
• Height: 18.5 mm / 0.728 inch
• Depth: 38.75 mm / 1.526 inch

Mechanical Data

• Housing sheet thickness: 1 … 3 mm / 0.039 … 0.118 inch
• Mounting type: Snap-in
• Suitable: For socket and plug

Material Data

• Color: Black
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.081 MJ
• Weight: 2.710 g

Environmental Requirements

• Processing temperature: -5 … +40 °C
• Continuous operating temperature: -35 … +85 °C
• Note on continuous operating temperature: Insulating parts for temperatures ≤ 105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821261162
• Customs tariff number Sales Organisation Germany: 39269097900
