Features

• simple circuits
• fast, secure installation

Approvals

• Lloyds Register, LR, 02/20050 (E6), IEC 61984

Specifications

Connection 1

• Pole No.: 5

Physical Data

• Width: 55.5 mm / 2.185 inch
• Height: 18.5 mm / 0.728 inch
• Depth: 38.7 mm / 1.524 inch

Mechanical Data

• Housing sheet thickness: 0.5 … 2 mm / 0.02 … 0.079 inch
• Mounting type: Snap-in
• Suitable: For socket and plug

Material Data

• Color: Black
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.000 MJ
• Weight: 5.310 g

Environmental Requirements

• Processing temperature: -5 … +40 °C
• Continuous operating temperature: -35 … +85 °C
• Note on continuous operating temperature: Insulating parts for temperatures ≤ 105 °C

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055144020571
• Customs tariff number Sales Organisation Germany: 39269097900
