Features

Approvals

• Underwriters Laboratories Inc., UR, E45171, UL 1977
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• Underwriters Laboratories Inc., UR, E45172, UL 1059
• DEKRA Certification B.V., KEMA/KEUR, 2190419.01, EN 60947
• DEKRA Certification B.V., CCA, NTR NL-7626, EN 60947
• DEKRA Certification B.V., CCA, NL-47799/A1, IEC 61984
• DEKRA Certification B.V., CCA, 2190419.02, EN 61984
• DEKRA Certification B.V., CSA, 1101144, C22.2 No. 158

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 250 V
• Rated surge voltage (III/3): 4 kV
• Rated voltage (III/2): 500 V
• Rated surge voltage (III/2): 4 kV
• Rated current: 32 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Pole No.: 15

Physical Data

• Pin spacing: 5 mm / 0.197 inch
• Width: 89.7 mm / 3.531 inch
• Height from the surface: 18.3 mm / 0.72 inch
• Depth: 22.2 mm / 0.874 inch

Mechanical Data

• Mounting type: Feedthrough flange

Plug-In Connection

• Contact type (pluggable connector): Male connector/plug
• Connector (connection type): For PCB
• Mismating protection: No
• Mating direction to the PCB: 0 °

Pcb Contact

• PCB Contact: THT

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.343 MJ
• Weight: 16.850 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: PL
• GTIN: 4017332412919
• Customs tariff number Sales Organisation Germany: 85366990990
